Keg Washer
the detailed info of the Keg Washer (Single - head 2 tanks 2 pumps) |
1. Material:SUS304 |
2. Power:380V 50HZ, 3 phase(customized for local power) |
3. Dimension:1200*1050*2030mm, packaging:1350*1160*2250mm |
4. Weight:238Kg, packaging: 369Kg |
5. Washing Capacity: 20-30pcs/h |
6. Power port: 3P+N+G |
7. Water tank material:SUS304, volume=100L (2 PCS) |
8. Heating method & Power consumption:optional Steam Coiler : 2KW & Electrical Heater: 14KW |
9. Temperature probe :NTC |
10. Time setting way:Siemens PLC 200 Smart |
11. Connect type: water inlet and drain outlet:1.5" Tri-clamp Steam inlet: DIN male fitting |
12. Pear type: A,S,D,G connection type(optional) |
13. EURO DIN AMERICAN 20L-60Lkeg |
Washing working procedure |
Lock down → air purge/drain off → hot water washing → air purge/drain off → caustic washing → air purge/to caustic tank → hot water 1 washing → air purge/drain off → hot water 2 washing → steam drain hot water → steam sterilized → steam keep pressure sterilized → CO2 purge/drain off → CO2 fill
Company Introduction |
Carry Brewtech has been supplying all kinds of customized Brewhouse, Fermenter, Bright tank, brewery auxiliaries and system turnkey solutions to more than 800 customers all over the world, industries including Beer, Kombucha, Wine, Gin, Rum.
With continuous R&D, innovative, value driven, you'll be served by the most cost-effective and suitable custom solution from our knowledgeable team.
Carry Brewtech takes pride in supplying the right equipment, training and service for your Industry. No matter how small or large your business is!
